Details

---

Valve is suitable for use on water pipelines as opening and closing. Working Temperature not exceeding 100°C. Working pressure PN 10.

Standards

1. Face to face is according to BS3464
2. Flange drilled is according to BS 10 Table E or D



Materials

Parts	Materials	Grade of Designation
Body	Cast Iron	HT 20 - 40
Bonnet	Cast Iron	HT 20 - 40
Stem	Stainless Steel	ZHPB 59 - 1
Disc	Cast Iron	HT 20 - 40
Bonnet Gasket	Compressed Asbestos	XB 200
Gland Packing	Lubricated Asbestos	YS 250F
Seat Ring	Cast Iron	HPB 59-1 35
